初效袋式过滤器

  • G4袋式空气过滤器
  • G4袋式空气过滤器
G4袋式空气过滤器G4袋式空气过滤器

G4袋式空气过滤器

  • 品牌:成净高科
  • 尺寸:定制
  • 效率:G4
  • 产品描述:G4袋式空气过滤器
  • 在线订购

初效袋式空气过滤器

Air filter bag filter early effect

特点Features

●可重复使用多次

●阻力小、风量大

●运用于空调系统的中级过滤

●Adopts reusable times

●Responding to small resistance, air

●Widely used in air conditioning system of intermediate filtration

构成材料及运行条件

Materials and operating conditions

●框材:铝合金或镀锌板外框

●External frane:Aluminum alloy steel or frame

●滤料材质:复合无纺布

●Filter material: new composite nonwoven fabric

●滤料颜色:白色

●Liao color: white

●密封条:醋酸乙酯

●Gasket:EVA

●使用温度、湿度:80℃、80%以内

●Use the highest temperature, humidity:80℃、80%

型号尺寸及其他参数

Standard specification

型号

model

外形尺寸

Outside Dimensions

(mm)

额定风量

Rated air flow

(m3/h)

初阻力

Initial resistance(Pa)

效率(级别)

Efficiency

(class)

滤料颜色

Liao color

袋数

pockets

CJ-S10-A1

495×295×500mm

20″×12″×20

1500m3/h


25~35Pa


25-35% G3


35-45% G4

White

5

CJ-S10-A2

495×495×500mm

20″×20″×20

2500m3/h

5

CJ-S10-A3

595×295×500mm

24″×12″×20

2000m3/h

6

CJ-S10-A4

595×495×500mm

24″×20″×20

3200m3/h

6

CJ-S10-A5

595×595×500mm

24″×24″×20

3800m3/h

8

CJ-S10-A6

495×295×600mm

20″×12″×24

1800m3/h

5

CJ-S10-A7

495×495×600mm

20″×20″×24

3200m3/h

5

CJ-S10-A8

595×295×600mm

24″×12″×24

2500m3/h

6

CJ-S10-A9

595×495×600mm

24″×20″×24

4000m3/h

6

CJ-S10-A10

595×595×600mm

24″×24″×24

4500m3/h

8

*可要据用户要求定制不同规格型号的过滤器

According to user requirements to customize different specifications and types of filters
